CELCON GC90UV | POM | UV Resistant
De
Celcon® acetal copolymer grade GC90UV is a specialty grade combining glass coupling for improved strength and stiffness and UV stabilization for improved performance in exposure to artificial lighting and sunlight.
| ISO Data | Mechanical properties | Value | Unit | Test Standard |
| Phys | Density | 1470 | kg/m³ | ISO 1183 |
| Mech | Mechanical properties | Value | Unit | Test Standard |
| Tensile modulus (1mm/min) | 4170 | MPa | ISO 527-2/1A | |
| Tensile stress at break (5mm/min) | 59 | MPa | ISO 527-2/1A | |
| Tensile strain at break (5mm/min) | 9 | % | ISO 527-2/1A | |
| Flexural modulus (23℃) | 3790 | MPa | ISO 178 | |
| Charpy notched impact strength @ 23℃ | 3.7 | kJ/m² | ISO 179/1eA | |
| Notched impact strength (Izod) @ 23℃ | 4.5 | kJ/m² | ISO 180/1A | |
| Therm | Thermal properties | Value | Unit | Test Standard |
| Melting temperature (10℃/min) | 167 | ℃ | ISO 11357-1,-2,-3 | |
| DTUL @ 1.8 MPa | 141 | ℃ | ISO 75-1/-2 | |
| SpecProd | Test specimen production | Value | Unit | Test Standard |
| Processing conditions acc. ISO | 9988-2 | - | Internal |
